Line Impedance Stabilisation Network (LISN)
LISNs are key components in EMC testing. Used to monitor undesirable emissions on the supply line, the LISN is inserted into the device under test’s supply line and utilised in conjunction with a measurement receiver or spectrum analyser. Typically, the receiver or spectrum analyser is operated by software such as EMCview. The software guarantees that the analyser’s settings are in accordance with CISPR 16 specifications and allows you to load and run pre-configured tests for all main EMC standards. The measurement data points are graphed along with the selected standard’s limits and can be exported as test report.
Manufacturer | Model | Impedance | Frequency Range | Path | Max Current | Max Voltage | EUT Socket | Additional Features |
---|---|---|---|---|---|---|---|---|
TekBox | TBOH01 | 5µH//50Ω | 150 kHz – 108 MHz | 1 | 10A | 60V nominal, Component rating: 250V | 4mm (banana) | |
TekBox | TBL0550-1 | 5µH//50Ω | 150 kHz – 108 MHz | 1 | 50A | 60V nominal, Component rating: 250V | Phoenix High Current | |
TekBox | TBL05100-1 | 5µH//50Ω | 150 kHz – 108 MHz | 1 | 100A | 60V nominal, Component rating: 250V | Phoenix High Current | |
TekBox | TBL5016-1 | 50µH//50Ω | 150 kHz – 30 MHz | 1 | 16A | 250V | Phoenix High Current | |
TekBox | TBL50100-1 | 50µH//50Ω | 150 kHz – 30 MHz | 1 | 100A | 250V | Phoenix High Current | |
TekBox | TBLCO8 | (50µH+5Ω)//50Ω | 9 kHz – 30 MHz | 2 | 8A | 240V | Country specific mains socket | Filter/Limiter/Attenuator switchable Artificial hand connection PE switchable: |
TekBox | TBL5016-2 | (50µH+5Ω)//50Ω | 9 kHz – 30 MHz | 2 | 16A | 240V | Country specific mains socket | Filter/Limiter/Attenuator switchable Artificial hand connection PE switchable: |
TEkBox | TBL5016-3 | (50µH+5Ω)//50Ω | 9 kHz – 30 MHz | 3 | 16A | 540V/240V | СЕЕ/ЕС60309 | Artificial hand connection PE switchable: 50Ω//50µH |
TekBox | TBL5032-3 | (50µH+5Ω)//50Ω | 9 kHz – 30 MHz | 3 | 32A | 540V/240V | СЕЕ/ЕС60309 | Artificial hand connection PE switchable: 50Ω//50µH |
TekBox | TBLM1 | LISN Mate |
