Description
SIGLENT SDS3054X HD Oscilloscope: 350MHz Bandwidth, 4 Channels, 4GSa/s Sample Rate, and 12-Bit High Resolution
The SIGLENT SDS3054X HD is a high-performance mixed signal oscilloscope designed for advanced signal analysis and measurement. Part of the SDS3000X HD series, this oscilloscope offers a comprehensive feature set ideal for both analogue and digital signal analysis.
Key Specifications:
- Bandwidth: 350 MHz
- Channels: 4 analogue channels and optional 16 digital channels
- Sample Rate: Up to 4 GSa/s
- Memory Depth: Up to 400 Mpts per channel
- Vertical Resolution: 12-bit ADC for superior waveform detail
Advanced Features:
- High-Resolution ADC: The 12-bit ADC provides up to 4096 quantization levels, offering 16 times the resolution of traditional 8-bit oscilloscopes. In high-resolution mode (ERES), the resolution can be increased to 16-bit, making waveform details clearer and more accurate.
- SPO Technology: Enables a maximum waveform capture rate of up to 200,000 waveforms per second in normal mode and up to 890,000 waveforms per second in Sequence mode, allowing for fast and detailed signal analysis.
- Low Noise Floor: Achieves a noise floor as low as 125 μVrms at full 350 MHz bandwidth, ensuring clean and precise measurements.
- Large Touchscreen Display: Features a 12.1” capacitive touch screen with a resolution of 1024 x 600, supporting multi-touch gestures for improved operational efficiency. Mouse control and remote web control via LAN are also supported.
- Powerful Triggering System: Includes intelligent trigger modes such as Edge, Slope, Pulse, Window, and more. Serial bus triggering and decoding support protocols including I2C, SPI, UART, CAN, LIN, with additional options for CAN FD, FlexRay, I2S, and more.
- Segmented Acquisition Mode: Divides the maximum record length into multiple segments (up to 80,000) with minimal dead time between segments, capturing qualifying events with high accuracy.
- History and Data Analysis: Provides History waveform recording with up to 80,000 frames, automatic measurements on over 50 parameters, and extensive data analysis functions including Search, Navigate, Digital Voltmeter, Counter, and Bode Plot.
- Math and Mask Test Functions: Supports up to 4 math traces with various mathematical operations and a high-speed hardware-based Mask Test function with a Mask Editor tool for creating custom masks.
- Optional Features: Includes an optional 50 MHz external waveform generator and 16 digital channels for enhanced mixed-signal analysis.
Connectivity:
- Interfaces: Two USB 3.0 Hosts, one USB 2.0 Host, USB 3.0 Device (USBTMC), 1000M LAN (VXI-11/Telnet/Socket/LXI), External Trigger In, Aux Out (Pass/Fail, Trigger Out).
- Remote Control: Built-in web server supports remote control over LAN using a web browser and SCPI remote control commands. External mouse and keyboard support enhance usability.
The SIGLENT SDS3054X HD oscilloscope is an advanced instrument offering high resolution, extensive memory depth, and powerful analysis capabilities, making it a valuable tool for engineers and technicians in a variety of fields.
Siglent SDS3000X-HD Oscilloscope Comparison Table
| MODEL | ANALOGUE BANDWIDTH | NUMBER OF CHANNELS | HIGHEST REAL-TIME SAMPLING RATE | HIGHEST WAVEFORM CAPTURE RATE | MAXIMUM STORAGE DEPTH | VERTICAL RESOLUTION |
|---|---|---|---|---|---|---|
| SDS3034X HD | 350MHz | 4 | 4GSa/s | 890,000 wfm/s | 400 Mpts | 12-bit |
| SDS3054X HD | 500MHz | 4 | 4GSa/s | 890,000 wfm/s | 400 Mpts | 12-bit |
| SDS3104X HD | 1GHz | 4 | 4GSa/s | 890,000 wfm/s | 400 Mpts | 12-bit |
