Tekbox TBCP2-250 10kHz to 250MHz RF Current Monitoring Probe

£580.85 (£697.02 inc VAT)

SKU: TBCP2-250 Categories: ,

Description


Tekbox TBCP2-250 RF Current Monitoring Probe

The TBCP2-250 is a 10 kHz to 250 MHz snap-on RF current monitoring probe. It has a very flat response with a 3dB bandwidth of 250 MHz and is characterized and usable over the frequency range from 10kHz to 250 MHz. The aperture of the RF current monitoring probe is 32 mm. Its transfer impedance is > 13 dB Ohm in the range from 700 kHz to 250 MHz.

Features:

  • Characterized frequency range: 10 kHz to 250 MHz
  • Aperture diameter: 32 mm
  • Outside diameter: 73 mm
  • Height: 20 mm
  • Weight: 320 g
  • Connector type: N female
  • Transfer impedance: 0 to 16 dBΩ between 100 kHz and 250 MHz
  • Max. primary current (DC – 400 Hz): 80 A
  • Max. primary current (RF): 3 A
  • Max. core temperature: 125 °C

Documentation

User Manual

Tekbox TBCP2-250 User Manual


Specifications
Characterised frequency range30 kHz to 250 MHz
Aperture diameter32 mm
Outside diameter73 mm
Height20mm
Weight320g
Connector typeN female
Transfer impedance0 to 14 dBΩ between 100 kHz and 250 MHz
Max. primary current (DC – 400 Hz)80 A
Max. primary current (RF)3A
Max. core temperature125 °C



Frequency (MHz)Transfer Impedance (dBΩ)Frequency (MHz)Transfer Impedance (dBΩ)
0.01-19.843012.85
0.02-12.424012.85
0.03-7.635012.86
0.04-4.556012.86
0.05-2.097012.86
0.06-0.498012.87
0.070.969012.85
0.082.1110012.85
0.092.9711012.83
0.13.8112012.81
0.28.6713012.79
0.310.6214012.79
0.411.5115012.83
0.512.0116012.88
0.612.3117012.94
0.712.5018013.02
0.812.6119013.12
0.912.6820013.22
112.7521013.32
212.8222013.39
312.8023013.45
412.8224013.48
512.8325013.52
612.8426013.55
712.8427013.59
812.8528013.67
912.8629013.77
1012.8230013.93
2012.81
