Siglent SDG2042X 2Ch, 40MHz, 1.2GSa/s, Function Generator

(2 customer reviews)

£408.00 (£489.60 inc VAT)

3 in stock (can be backordered)

Availability: Stock models delivered next working day (UK only) for orders placed before 16:30 (Mon - Fri)

Free Shipping Price Match Guarantee

Description


Siglent SDG2042X Function Generator

The SDG2042X is a 2CH, 40MHz Function Generator with a maximum sampling rate of 1.2GSa/s. Siglent’s SDG2000X is a series of dual-channel function/arbitrary waveform generators with specifications of up to 120MHz maximum bandwidth, 1.2 GSa/s sampling rate and 16-bit vertical resolution. The proprietary TrueArb & EasyPulse techniques help to solve the weaknesses inherent in traditional DDS generators when generating arbitrary, square and pulse waveforms. With advantages above, SDG2000X can provide users with a variety of high fidelity and low jitter signals, which can meet the growing requirements of complex and extensive applications.

  • Innovative EasyPulse technology, capable of generating lower jitter Square or Pulse waveforms, brings a wide range and extremely high precision in pulse width and rise/fall times adjustment
  • Plenty of analogue and digital modulation types: AM, DSB-AM, FM, PM, PSK, FSK, ASK, and PWM
  • Sweep and Burst function, Harmonics mode supported
  • High precision Frequency counter
  • Standard interfaces: USB Device, USB Host, LAN (VXI-11), and GPIB (optional)
  • 4.3″ touchscreen display for easier operation

Siglent SDG2000X Function Generator Comparison Table

MODELMAX OUTPUT FREQUENCYMAX SAMPLING RATEVERTICAL RESOLUTIONWAVEFORM LENGTHCHANNELS
SDG2042X40MHz1.2GSa/s16-bit8pts to 8Mpts2
SDG2082X80MHz1.2GSa/s16-bit8pts to 8Mpts2
SDG2122X120MHz1.2GSa/s16-bit8pts to 8Mpts2

Product Videos

Frequency Characteristics
ParameterMin.Typ.Max.UnitCondition
Resolution1μHz
Initial Accuracy-1

-2

+1

+2

ppm

ppm

25℃

0~40℃

1st-year aging-1+1ppm25℃
10-year aging-3.5+3.5ppm25℃
Sine Characteristics
ParameterMin.Typ.Max.UnitCondition
Frequency1μ
1μ
1μ
120M
80M
40M
Hz
Hz
Hz
SDG2122X
SDG2082X
SDG2042X
Harmonic Distortion-65
-60
-55
-50
-45
-40
-38
dBc
dBc
dBc
dBc
dBc
dBc
dBc
0 dBm, 0~10 MHz (Included)
0 dBm, 10~20 MHz (Included)
0 dBm, 20~40 MHz (Included)
0 dBm, 40~60 MHz (Included)
0 dBm, 60~80 MHz (Included)
0 dBm, 80~100 MHz (Included)
0 dBm, 100~120 MHz (Included)
Total Harmonic Distortion0.075%0 dBm, 10 Hz ~ 20 kHz
Non Harmonic Spurious-70
-65
dBc
dBc
≤50 MHz
>50 MHz
Arbitrary Wave Characteristics
ParameterMin.Typ.Max.UnitCondition
Frequency1μ20MHz
Waveform Length88Mpts
Sampling Rate1μ
300
75MSa/s
MSa/s
TrueArb mode
DDS mode
Vertical Solution16bit
Jitter (rms)150ps1 Vpp, 50Ω Load, TrueArb mode
DC Characteristics
ParameterMin.Typ.Max.UnitCondition
Range-10
-5
10
5
V

V

HiZ load

50Ωload

Accuracy±(1%+2mV)HiZ load
General Specifications
Power
ParameterMin.Typ.Max.UnitCondition
Voltage100 – 240 Vrms (± 10%), 50 / 60 Hz
100 – 120 Vrms (± 10%), 400 Hz
Power Consumption25.550WDual channels, Sine, 1kHz, 10Vpp, 50Ω load
Display
Colour depth24bit
Contrast ratio350:1
Luminance300cd/m2
Touch panel typeResistive
Environment
Operating temperature040℃
Storage temperature-2060℃
Operating humidity5
5
90
50
%
%
≤ 30 ℃
40 ℃
Non-operating humidity595%
Operating altitude3048m≤ 30 ℃
Non-operating altitude15000m

Note*

Specifications are liable to change. For the full list of Specifications, please see the products datasheet located under the ‘Documentation’ tab.
