The SDG2082X is a 2CH, 80MHz Function Generator with a maximum sampling rate of 1.2GSa/s. Siglent’s SDG2000X is a series of dual-channel function/arbitrary waveform generators with specifications of up to 120MHz maximum bandwidth, 1.2 GSa/s sampling rate and 16-bit vertical resolution. The proprietary TrueArb & EasyPulse techniques help to solve the weaknesses inherent in traditional DDS generators when generating arbitrary, square and pulse waveforms. With advantages above, SDG2000X can provide users with a variety of high fidelity and low jitter signals, which can meet the growing requirements of complex and extensive applications.
Innovative EasyPulse technology, capable of generating lower jitter Square or Pulse waveforms, brings a wide range and extremely high precision in pulse width and rise/fall times adjustment
Plenty of analogue and digital modulation types: AM, DSB-AM, FM, PM, PSK, FSK, ASK, and PWM
Sweep and Burst function, Harmonics mode supported
High precision Frequency counter
Standard interfaces: USB Device, USB Host, LAN (VXI-11), and GPIB (optional)
4.3″ touchscreen display for easier operation
Siglent SDG2000X Function Generator Comparison Table
Specifications are liable to change. For the full list of Specifications, please see the products datasheet located under the ‘Documentation’ tab.
