Siglent SDS3000X-HD 12 Bit High Resolution Oscilloscope

SIGLENT SDS3000X HD Oscilloscope: 12-Bit High-Resolution with 1 GHz, 500 MHz, and 350 MHz Bandwidth Options

The SIGLENT SDS3000X HD series oscilloscopes are designed for advanced signal analysis, offering exceptional clarity and precision with their 12-bit analog-to-digital converters (ADC). Available with 1 GHz, 500 MHz, and 350 MHz bandwidth options, these oscilloscopes provide unparalleled detail and accuracy for professionals in design, debugging, and testing.

Key Specifications:

• Bandwidth: Available in 1 GHz, 500 MHz, and 350 MHz models, catering to a wide range of high-frequency applications.
• Storage Depth: Up to 400 Mpts per channel, allowing for extensive data recording and in-depth analysis.
• Vertical Resolution: 12-bit ADC with 4096 quantization levels, providing 16 times the resolution of traditional 8-bit oscilloscopes.
• Real-Time Sampling Rate: Up to 4 GSa/s, ensuring accurate capture of high-speed waveforms.
• Waveform Capture Rate: Capable of up to 890,000 waveforms per second, allowing for fast and detailed signal analysis.
• Low Noise Floor: As low as 125 μVrms across the full bandwidth, ensuring precise measurements without interference.

12-Bit ADC and Enhanced Resolution:

The SDS3000X HD series features a 12-bit high-resolution ADC, offering up to 4096 quantization levels for detailed waveform analysis. In high-resolution mode (ERES), the resolution can be further enhanced to 16-bit, making even the most subtle signal variations visible. This advanced resolution capability is particularly beneficial when analyzing complex circuits, such as the LLC half-bridge conversion circuit, where observing the dead time between driving signals is crucial. The superior clarity provided by a 12-bit oscilloscope ensures that waveform details are significantly clearer compared to an 8-bit oscilloscope.

Advanced Signal Analysis:

With a low noise floor, extensive storage depth, and high sampling rate, the SIGLENT SDS3000X HD series is designed for professionals who demand the highest level of performance. Whether you’re working in research, development, or field testing, these oscilloscopes offer the precision and reliability required to capture and analyze even the most complex signals with confidence.
