Description


Siglent SSG3032X-IQE Signal Generator

SIGLENT’S SSG3032X-IQE ( in-phase (I) and a quadrature (Q) ) signal generator has a frequency range of 9kHz to 2.1GHz. It provides normal analog modulation such as AM, FM, and PM, as well as a pulse modulation and pulse train generator. In addition, when used with baseband generator such as SDG6000X, it can generate IQ modulated signals. With their high accuracy and pure outputs, the SSG3000X series is the right choice for R&D, education, and manufacturing.

  • Frequency up to 3.2GHz
  • 0.01Hz frequency setting resolution
  • Level output from -110 dBm to +13dBm
  • Maximum level up to +20dBm (typ.)
  • Phase Noise: -110dBc/Hz @ 1GHz, 20kHz offset (typ.)
  • Level accuracy ≤0.7 dB (typ.)
  • Provides
  • AM, FM, &PM analog modulation with internal, external or Int+Ext source
  • Pulse modulation, on/off ratio ≥70 dBc
  • Pulse train Generator (option)
  • External IQ modulation with SDG6000X as the baseband IQ signal
  • USB-power meter measurement kit
  • 5 inch TFT capacitive touch screen, Mouse and keyboard supported
  • Web Browser Remote Control on PC and mobile Terminals
  • Standard interface include USB Host, USB Device (USB TMC), LAN (VXI-11, Socket, Telnet). Optional interface: GPIB

Siglent SSG3000X RF Signal Generator Comparison Table

MODEL Frequency Range FREQUENCY RESOLUTION AMPLITUDE RESOLUTION PHASE NOISE EXTERNAL I/Q MODULATION DISPLAY
SSG3021X 9kHz to 2.1GHz 0.01Hz 0.01dB 110dBc/Hz @ 1GHz, offset 20kHz (typ.) No 5 Inch Capacitance Touch Screen, RGB (800*480)
SSG3021X-IQE 9kHz to 2.1GHz 0.01Hz 0.01dB 110dBc/Hz @ 1GHz, offset 20kHz (typ.) Yes 5 Inch Capacitance Touch Screen, RGB (800*480)
SSG3032X 9kHz to 3.2GHz 0.01Hz 0.01dB 110dBc/Hz @ 1GHz, offset 20kHz (typ.) No 5 Inch Capacitance Touch Screen, RGB (800*480)
SSG3032X-IQE 9kHz to 3.2GHz 0.01Hz 0.01dB 110dBc/Hz @ 1GHz, offset 20kHz (typ.) Yes 5 Inch Capacitance Touch Screen, RGB (800*480)

Product Images

Product Videos

YouTube Video

Documentation

SSG3000X User ManualSSG3000X Datasheet
SSG3000X Quick Guide

SSG3000X Specifications
Model SSG3021X SSG3021X-IQE SSG3032X SSG3032X-IQE
Frequency Range CW MODE 9 kHz~2.1 GHz CW MODE 9 kHz~2.1 GHz IQ MODE 10 MHz~2.1 GHz CW MODE 9 kHz~3.2 GHz CW MODE 9 kHz~3.2 GHz IQ MODE 10 MHz~3.2 GHz
Frequency Resolution 0.01 Hz 0.01 Hz 0.01 Hz 0.01 Hz
Setting time <5 ms (typ.), ALC ON
<10 ms (typ.), ALC OFF (S&H)		 <5 ms (typ.), ALC ON
<10 ms (typ.), ALC OFF (S&H)		 <5 ms (typ.), ALC ON
<10 ms (typ.), ALC OFF (S&H)		 <5 ms (typ.), ALC ON
<10 ms (typ.), ALC OFF (S&H)
Frequency Band
Band Frequency range | N Frequency range | N Frequency range | N Frequency range | N
1 9 kHz≤f≤1 MHz | 0.25 9 kHz≤f≤1 MHz | 0.25 9 kHz≤f≤1 MHz | 0.25 9 kHz≤f≤1 MHz | 0.25
2 1 MHz<f≤250 MHz | 0.5 1 MHz<f≤250 MHz | 0.5 1 MHz<f≤250 MHz | 0.5 1 MHz<f≤250 MHz | 0.5
3 250 MHz<f≤500 MHz | 0.125 250 MHz<f≤500 MHz | 0.125 250 MHz<f≤500 MHz | 0.125 250 MHz<f≤500 MHz | 0.125
4 500 MHz<f<1000 MHz | 0.25 500 MHz<f<1000 MHz | 0.25 500 MHz<f<1000 MHz | 0.25 500 MHz<f<1000 MHz | 0.25
5 1000 MHz ≤f<2000 MHz | 0.5 1000 MHz ≤f<2000 MHz | 0.5 1000 MHz ≤f<2000 MHz | 0.5 1000 MHz ≤f<2000 MHz | 0.5
6 2000 MHz≤f≤3200 MHz | 1 2000 MHz≤f≤3200 MHz | 1 2000 MHz≤f≤3200 MHz | 1 2000 MHz≤f≤3200 MHz | 1
Frequency Reference
Reference frequency 10.000000 MHz 10.000000 MHz 10.000000 MHz 10.000000 MHz
Initial calibration accuracy <0.2 ppm <0.2 ppm <0.2 ppm <0.2 ppm
Temperature stability <1 ppm/year, 0℃ ~50℃ <1 ppm/year, 0℃ ~50℃ <1 ppm/year, 0℃ ~50℃ <1 ppm/year, 0℃ ~50℃
Frequency aging rate <0.5 ppm/first year, 3.0 ppm/20 years <0.5 ppm/first year, 3.0 ppm/20 years <0.5 ppm/first year, 3.0 ppm/20 years <0.5 ppm/first year, 3.0 ppm/20 years
Frequency sweep
Sweep type frequency step (linear or logarithmic step)
arbitrary list		 frequency step (linear or logarithmic step)
arbitrary list		 frequency step (linear or logarithmic step)
arbitrary list		 frequency step (linear or logarithmic step)
arbitrary list
Sweep range full frequency range full frequency range full frequency range full frequency range
Sweep sheep triangle, saw-tooth triangle, saw-tooth triangle, saw-tooth triangle, saw-tooth
Sweep mode single, continuous single, continuous single, continuous single, continuous
Step spacing linear, logarithmic linear, logarithmic linear, logarithmic linear, logarithmic
Number of points step sweep 2~65535
list sweep 2~500		 step sweep 2~65535
list sweep 2~500		 step sweep 2~65535
list sweep 2~500		 step sweep 2~65535
list sweep 2~500
Dwell time range 10 ms~100 s 10 ms~100 s 10 ms~100 s 10 ms~100 s
Dwell time setting resolution 0.1 ms 0.1 ms 0.1 ms 0.1 ms
Trigger source auto, keyboard, external connector, bus auto, keyboard, external connector, bus auto, keyboard, external connector, bus auto, keyboard, external connector, bus
Trig slop positive, negative when trigger source is external positive, negative when trigger source is external positive, negative when trigger source is external positive, negative when trigger source is external
General Specifications
Display TFT LCD, RGB (800*480), 5 inch capacitive touch screen TFT LCD, RGB (800*480), 5 inch capacitive touch screen TFT LCD, RGB (800*480), 5 inch capacitive touch screen TFT LCD, RGB (800*480), 5 inch capacitive touch screen
Storage internal (Flash) 256 M Byte ,external (USB storage device) internal (Flash) 256 M Byte ,external (USB storage device) internal (Flash) 256 M Byte ,external (USB storage device) internal (Flash) 256 M Byte ,external (USB storage device)
Source input voltage range (AC) 100 V~240 V (±10%)
AC frequency supply 100 V to 240 V, 50/60 Hz;
supply 100V to 120 V, 400 Hz
power consumption 35 W with all function working		 input voltage range (AC) 100 V~240 V (±10%)
AC frequency supply 100 V to 240 V, 50/60 Hz;
supply 100V to 120 V, 400 Hz
power consumption 35 W with all function working		 input voltage range (AC) 100 V~240 V (±10%)
AC frequency supply 100 V to 240 V, 50/60 Hz;
supply 100V to 120 V, 400 Hz
power consumption 35 W with all function working		 input voltage range (AC) 100 V~240 V (±10%)
AC frequency supply 100 V to 240 V, 50/60 Hz;
supply 100V to 120 V, 400 Hz
power consumption 35 W with all function working
Temperature Working temperature 0 ℃ to 50 ℃ , Storage temperature -20 ℃ to 70 ℃ Working temperature 0 ℃ to 50 ℃ , Storage temperature -20 ℃ to 70 ℃ Working temperature 0 ℃ to 50 ℃ , Storage temperature -20 ℃ to 70 ℃ Working temperature 0 ℃ to 50 ℃ , Storage temperature -20 ℃ to 70 ℃
Humidity 0 ℃ to 30 ℃ , ≤95% relative humidity;
30 ℃ to 50 ℃ , ≤75% relative humidity		 0 ℃ to 30 ℃ , ≤95% relative humidity;
30 ℃ to 50 ℃ , ≤75% relative humidity		 0 ℃ to 30 ℃ , ≤95% relative humidity;
30 ℃ to 50 ℃ , ≤75% relative humidity		 0 ℃ to 30 ℃ , ≤95% relative humidity;
30 ℃ to 50 ℃ , ≤75% relative humidity
Dimensions W×H×D=338×113×369 mm W×H×D=338×113×369 mm W×H×D=338×113×369 mm W×H×D=338×113×369 mm
Weight contain IQ modulator board 4.84 kg contain IQ modulator board 4.84 kg contain IQ modulator board 4.84 kg contain IQ modulator board 4.84 kg

Note* Specifications are liable to change. For the full list of Specifications, please see the products datasheet located under the ‘Documentation’ tab.
