Siglent SSG3021X-IQE Plus 2.1 GHz RF Signal Generator with External I/Q Modulation
The Siglent SSG3021X-IQE Plus combines a 9 kHz to 2.1 GHz RF signal generator with external I/Q modulation capability from 10 MHz to 2.1 GHz. Designed for applications requiring both conventional analogue modulation and more complex modulated signals, it can be paired with an external baseband source such as a Siglent SDG6000X to generate vector and multi-tone signals.
| Frequency Range | 9 kHz to 2.1 GHz (SSG3021X Plus / SSG3021X-IQE Plus) 9 kHz to 3.2 GHz (SSG3032X Plus / SSG3032X-IQE Plus) |
|---|---|
| IQ Frequency Range | 10 MHz to 2.1 GHz (SSG3021X-IQE Plus) 10 MHz to 3.2 GHz (SSG3032X-IQE Plus) |
| Frequency Resolution | 0.01 Hz |
| Amplitude Resolution | 0.01 dB |
| Level Setting Range | -110 dBm to +9 dBm (9 kHz to 100 kHz) -110 dBm to +15 dBm (100 kHz to 1 MHz) -110 dBm to +20 dBm (1 MHz to 3.2 GHz) |
| Level Performance Range | -110 dBm to +5 dBm (9 kHz to 100 kHz) -110 dBm to +10 dBm (100 kHz to 1 MHz) -110 dBm to +13 dBm (1 MHz to 3.2 GHz) |
| Level Accuracy | ≤ ±0.7 dB (typ.) |
| Phase Noise | -117 dBc/Hz at 1 GHz, 20 kHz offset (typ.) |
| Harmonics | < -30 dBc, 1 MHz to 3.2 GHz, output ≤ +13 dBm |
| Pulse On/Off Ratio | >63 dBc (1 MHz to 250 MHz) >68 dBc (250 MHz to 3.2 GHz) |
| Pulse Rise/Fall Time | <15 ns (typ.) |
| Modulation | AM, FM, PM and pulse modulation |
| External I/Q Bandwidth | Baseband I or Q: <100 MHz (typ.) RF (I+Q): <200 MHz (typ.) IQE models only |
| Frequency Sweep | Linear/logarithmic step and arbitrary list sweep |
| Step Sweep Points | 2 to 65,535 |
| List Sweep Points | 1 to 500 |
| Reference | Internal/external 10 MHz; optional 10M_OCXO_L high-stability OCXO |
| Display | 5-inch capacitive touchscreen, 800 × 480 |
| Interfaces | USB Host, USB Device, LAN; optional GPIB via USB-GPIB adapter |
| Dimensions | 338 × 113 × 369 mm (W × H × D) |
| Weight | 4.84 kg |
