Siglent SDG800 Function Generator Front

Siglent SDG830 1Ch, 30MHz, 125MSa/s, Function Generator

£172.00 (Β£206.4 inc VAT)

Only 1 left in stock!

Availability: Stock models delivered next working day (UK only) for orders placed before 16:30 (Mon - Fri)

SKU: SDG830 Category: Tag: Brand:

Description


Siglent SDG830 Function Generator

The SDG830 is a 30MHz, 1CH Function Generator with a maximum sampling rate of 125MSa/s. The SDG800 series function/arbitrary waveform generator family outputs waveform functions up to up to 5 MHz (pulse), 10 MHz (square), 30 MHz (sine) and has a sampling rate of 125 MSa/s. They are powered with SIGLENT’s EasyPulse technology which produces low jitter, fast rising/falling edges without being affected by frequency, even at low duty cycle settings, allowing the user a wide range of pulse widths and transition times. This results in a much more versatile generator than other similar DDS designs.

  • Innovative EasyPulse technology can output pulses with low jitter and quick rising/falling edges
  • Standard interfaces: USB Device, USB Host, supports U-Disk storage
  • 10 Nonvolatile storage spaces for user’s arbitrary waveforms
  • Can be seamlessly connected to SIGLENT Digital Storage Oscilloscope
  • Includes EasyWave, the powerful arbitrary waveform editing software
  • Advanced DDS technology, 125 MSa/s sampling rate, 14-bit vertical resolution
  • Single channel output, 5 standard waveforms, 46 built-in arbitrary waveforms (including DC)
  • Complete modulation functions: AM, DSB-AM, FM, PM, FSK, ASK, PWM, Linear/Logarithmic sweep, and burst

Product Images

Product Videos

YouTube Video
YouTube Video
YouTube Video
YouTube Video
YouTube Video

    Standard Hardware Accessories

Additional information

Specification
Model SDG810 SDG830
Max. output
frequency		 10MHz 30MHz
Output channels 1 1
Sample rate 125MSa/s 125MSa/s
Arbitrary waveform
length		 16kpts 16kpts
Frequency resolution 1ΞΌHz 1ΞΌHz
vertical resolution 14bits 14bits
Waveform Sine, Square, Ramp, Pulse, Gaussian Noise. 46 built-in arbitrary
waveforms(include DC)		 Sine, Square, Ramp, Pulse, Gaussian Noise. 46 built-in arbitrary
waveforms(include DC)
Modulation AM, DSB-AM, FM, PM, FSK, ASK, PWM, Sweep, Burst AM, DSB-AM, FM, PM, FSK, ASK, PWM, Sweep, Burst
Standard interface USB Host & USB Device USB Host & USB Device
Dimension W x H x D=229mm x 105mm x 281mm W x H x D=229mm x 105mm x 281mm
Frequency Specification
Model SDG810 SDG830
Waveform Sine, Square, Ramp, Pulse, Noise, Arbitrary Sine, Square, Ramp, Pulse, Noise, Arbitrary
Sine 1ΞΌHz ~ 10MHz 1ΞΌHz ~ 30MHz
Square 1ΞΌHz ~ 10MHz 1ΞΌHz ~ 30MHz
Pulse 500ΞΌHz ~ 5MHz 500ΞΌHz ~ 5MHz
Ramp/Triangular 1ΞΌHz ~ 300kHz 1ΞΌHz ~ 300kHz
Gaussian white noise >10MHz (-3dB) >30MHz (-3dB)
Arbitrary 1ΞΌHz ~ 5MHz 1ΞΌHz ~ 5MHz
Resolution 1ΞΌHz 1ΞΌHz
Accuracy Within 90days Β±50ppm within 1 year Β±100ppm Within 90days Β±50ppm within 1 year Β±100ppm
Temperature coefficient <5ppm/Β°C <5ppm/Β°C
Output Specification
Model SDG810 SDG830
Amplitude 2mVpp~10Vpp(50Ξ©,≀10MHz)
2mVpp~5Vpp(50Ξ©,>10MHz)
4mVpp ~ 20 Vpp（High impedance, <10MHzοΌ‰ 4mVpp ~ 10Vpp（High impedance,>10MHzοΌ‰		 2mVpp~10Vpp(50Ξ©,≀10MHz)
2mVpp~5Vpp(50Ξ©,>10MHz)
4mVpp ~ 20 Vpp（High impedance, <10MHzοΌ‰ 4mVpp ~ 10Vpp（High impedance,>10MHzοΌ‰
Vertical accuracy (100 kHz sine) Β±(1mVpp +0.3dB of setting value) Β±(1mVpp +0.3dB of setting value)
Amplitude flatness (compared to
100 kHz sine,5Vpp)		 Β±0.3 dB Β±0.3 dB
Impedance 50Ξ© 50Ξ©
Protection short-circuit protection short-circuit protection
General Specification
Model SDG810 SDG830
Display type 3.5 inch TFT-LCD 3.5 inch TFT-LCD
Resolution 320Γ—RGBΓ—240 320Γ—RGBΓ—240
Colour Depth 24bit 24bit
Contrast Ratio 350:1 (typical) 350:1 (typical)
Luminance 300cd/m (typical) 300cd/m (typical)
Voltage 100~240 VACRMS, 50/60Hz
100~120 VACRMS, 440Hz		 100~240 VACRMS, 50/60Hz
100~120 VACRMS, 440Hz
Consumption <30W <30W
Fuse 1.25A, 250V 1.25A, 250V
Temperature Operation:0Β°C~40Β°C
Storage:-20Β°C~60Β°C		 Operation:0Β°C~40Β°C
Storage:-20Β°C~60Β°C
Humidity range Below +35℃:≀90% relative humidity
+35℃~+40℃:≀60% relative humidity		 Below +35℃:≀90% relative humidity
+35℃~+40℃:≀60% relative humidity
Altitude Operation: below 3,000 meters
Storage: below 15,000 meters		 Operation: below 3,000 meters
Storage: below 15,000 meters
Dimension Width:229mm
Height:105mm
Depth:281mm		 Width:229mm
Height:105mm
Depth:281mm
Weight N.W: 2.6Kg
G.W: 3.4Kg		 N.W: 2.6Kg
G.W: 3.4Kg

Note*

Specifications are liable to change. For the full list of Specifications, please see the products datasheet located under the ‘Documentation’ tab.
