The SDG1032X is a 2CH, 30MHz Function Generator with a maximum sampling rate of 150MSa/s. Siglent’s SDG1000X is a series of dual-channel function/arbitrary waveform generators with specifications that include up to 60MHz maximum bandwidth, 150MSa/s sampling rate and 14-bit vertical resolution. The proprietary EasyPulse & TrueArb technique helps to solve the weaknesses inherent in traditional DDS generators when generating pulse waveforms, and the special square generator is capable of generating square waveforms up to 60MHz in frequency with low jitter. With these advantages, the SDG1000X can provide users with a variety of high fidelity / low jitter signals while meeting the growing requirements of a wide range of complex and varied applications.
Features:
Special circuit for Square wave function can generate Square waves up to 60MHz with jitter less than 300 ps+0.05 ppm of period
Plenty of analogue and digital modulation types: AM, DSB-AM, FM, PM, FSK, ASK, PSK and PWM
Sweep and Burst functions
Harmonics Generator function
Waveform Combining function
High precision Frequency Counter
Standard interfaces: USB Hose, USB Device, (USBTMC), LAN (VXI-11)
Optional interface: GPIB
4.3″ TFT-LCD display
Siglent SDG1000X Function Generator Comparison Table
Specifications are liable to change. For the full list of Specifications, please see the products datasheet located under the βDocumentationβ tab.
6 reviews for Siglent SDG1032X 2Ch, 30MHz, 150MSa/s, Function Generator
Rated 5 out of 5
Stephen Roberts (verified owner)–
Excellent product, easy and straightforward to use. Well built and robust. Fast efficient delivery.
Rated 5 out of 5
Chris S –
Ridiculously good value for money. Nice and clear interface and programming information. Using as an HF RF signal generator and calibration signal source.
Rated 5 out of 5
Martin W –
.
Rated 5 out of 5
Curtis –
Very fast delivery, great device!
Rated 5 out of 5
William H –
I found the build of this instrument robust and given the extensive functionality provided this is a very compact unit. It has an all up weight of approx 4Kg. The dual o/p is very useful for generating twin waveforms with capability to control phase shift. Rise time of the pulse o/p function is not that sharp (but to spec.) but can be squared up if need be by ext. conditioning. All in all this kit has a very good spec. At the price.
Rated 5 out of 5
Richard –
The function generator was despatched within hours of placing the order and arrived next day. The whole service was very professional, would definitely use these guys in the future.
