Siglent SCP5150 DC-12MHz 150A Current Probe

Siglent SCP5150 DC-12MHz 150A Current Probe

£2525.00 (£3030 inc VAT)

Available on back-order, delivery normally 1 - 2 weeks

Availability: Stock models delivered next working day (UK only) for orders placed before 16:30 (Mon - Fri)

SKU: SCP5150 Category:

Description


This product is a Current Probe that can be used with Siglent Oscilloscopes.

See the “Specification” Tab for more information.



See other models: SCP5030A, SCP5030, SCP5500

Model SCP5030 (A) SCP5150 SCP5500
Bandwidth
(-3 dB)		 SCP5030 DC-50 MHz DC-12 MHz DC-2 MHz
SCP5030A DC-100 MHz
Rise Time SCP5030 ≤ 7 ns ≤29 ns ≤175 ns
SCP5030A ≤ 3.5 ns
Continuous maximum input range SCP5030 30 Arms 150 Arms 500 Arms
SCP5030A 30 Arms
Max peak current value 50 Apk 300 Apk 750 Apk
Range 5 A 1X 30 A 10X 75 A 10X
30 A 10X 150 A 100X 500 A 100X
Overload 5 A ≥5 A 30 A ≥30 A 75 A ≥75 A
30 A ≥50 A 150 A ≥300 A 500 A ≥750 A
Current transfer ratio 5 A 1 V/A 30 A 0.1 V/A 75 A 0.1 V/A
30 A 0.1 V/A 150 A 0.01 V/A 500 A 0.01 V/A
Resolution 5 A 1 mA 30 A 10 mA 75 A 10 mA
30 A 10 mA 150 A 100 mA 500 A 100 mA
Accuracy
(DC, 45-66 Hz)		 5 A ±1%±1 mA 30 A ±1%±10 mA 75 A ±1%±10 mA
30 A ±1%±10 mA 150 A ±1%±100 mA 500 A ±1%±100 mA
Input resistance SCP5030
SCP5030A
Delay Probe 14 ns 36 ns 42 ns
BUS cable
(1 .5m)		 7.5 ns
Terminal load requirements ≥100 kΩ
Power Supply Directly powered by the oscilloscope through SAPBUS
Voltage of insulated wire 300 V CAT I 600 V CATII 300 V CATIII
Terminal load requirements EN61010-1: 2010+A1:2019 EN 61010-2-032:2019
Terminal load requirements EN61326-1:2013 EN61000-3-2:2014 EN61000-3-3:2013
