Siglent SPD3303X 2x 0-32V (3.2A), 2.5V/3.3V/5.0V (3.2A), 220W, Programmable Bench DC Power Supply

£429.00 (£514.80 inc. VAT)

5 in stock (can be backordered)

Availability: Stock models delivered next working day (UK only) for orders placed before 16:30 (Mon - Fri)

SKU: SPD3303X Categories: , Tag: Brand:

Description


Siglent SPD3303X Programmable Bench DC Power Supply

The SPD3303X is a 2x 0-32V (3.2A), 2.5V/3.3V/5.0V (3.2A), 220W Bench Programmable DC Power Supply. Siglent’s SPD3000X Series Programmable Linear DC Power Supply has a 4.3 inch TFT-LCD display, supports Remote Programming and has a Real Time Wave Display. The 3000X family has three isolated outputs; two adjustable channels and one selectable channel from 2.5V, 3.3V, and 5V. It also has output short and overload protection and can be used in production and development.

Product Images

Product Videos

YouTube Video
General Specifications
Model SPD3303X-E SPD3303X
Channel CH1 output voltage：0 ～ 32V， output current：0 ～ 3.2A
CH2 output voltage：0 ～ 32V， output current：0 ～ 3.2A
CH3 output voltage：2.5/3.3/5.0V， output current ：3.2A		 CH1 output voltage：0 ～ 32V， output current：0 ～ 3.2A
CH2 output voltage：0 ～ 32V， output current：0 ～ 3.2A
CH3 output voltage：2.5/3.3/5.0V， output current ：3.2A
Display 4.3 inch true color TFT-LCD
4 digits voltage 3 digits current		 4.3 inch true color TFT-LCD
5 digits voltage 4 digits current
Resolution 10mV/10mA 10mV/10mA
Program Accuracy Voltage ±（0.5% of reading+2digits） Voltage±（0.03% of reading+10mV）
Current ±（0.5% of reading+2digits）		 Voltage ±（0.5% of reading+2digits） Voltage±（0.03% of reading+10mV）
Current ±（0.5% of reading+2digits）
Readback Accuracy Voltage ±（0.5% of reading+2digits） Voltage±（0.03% of reading+10mV）
Current ±（0.5% of reading+2digits）		 Voltage ±（0.5% of reading+2digits） Voltage±（0.03% of reading+10mV）
Current ±（0.5% of reading+2digits）
Constant Voltage Mode
Line Regulation ≤0.01%+3mV ≤0.01%+3mV
Load Regulation ≤0.01%+3mV ≤0.01%+3mV
Ripple & Noise ≤1mVrms（5Hz ～ 1MHz） ≤1mVrms（5Hz ～ 1MHz）
Recovery Time ＜ 50μs（50% load change， minimum load 0.5A） ＜ 50μs（50% load change， minimum load 0.5A）
Constant Current
Mode
Line Regulation ≤0.2%+3mA ≤0.2%+3mA
Load Regulation ≤0.2%+3mA ≤0.2%+3mA
Ripple & Noise ≤3mArms ≤3mArms
Parallel Mode
Line Regulation ≤0.01%+3mV ≤0.01%+3mV
Load Regulation ≤0.01%+3mV ≤0.01%+3mV
Series Mode
Line Regulation ≤0.01%+5mV ≤0.01%+5mV
Load Regulation ≤300mV ≤300mV
CH3
Output Voltage (2.5/3.3/5V) ±8% (2.5/3.3/5V) ±8%
Line Regulation ≤0.01%+3mV ≤0.01%+3mV
Load Regulation ≤0.01%+3mV ≤0.01%+3mV
Ripple & Noise ≤1mVrms（5Hz ～ 1MHz） ≤1mVrms（5Hz ～ 1MHz）
Locking Key Yes Yes
Memory Save/Recall 5 Sets 5 Sets
Max Output Power 220W 220W
Power Source AC 100V/120V/220V/230V ±10% 50/60Hz AC 100V/120V/220V/230V ±10% 50/60Hz
Standard Configuration Interface USB Device, LAN USB Device, LAN
Insulation Case to Terminal ≥20MΩ (DC 500V)
Case to AC line ≥30MΩ (DC 500V)		 Case to Terminal ≥20MΩ (DC 500V)
Case to AC line ≥30MΩ (DC 500V)
Operating Environment Outdoor Usage:
Elevation：≤2000m Environment Temperature 0~40℃ Relative Humidity≤80%
Installation Level: Ⅱ Pollution Level：2		 Outdoor Usage:
Elevation：≤2000m Environment Temperature 0~40℃ Relative Humidity≤80%
Installation Level: Ⅱ Pollution Level：2
Storage Environment Environment Temperature: -10~70℃ Relative Humidity≤70% Environment Temperature: -10~70℃ Relative Humidity≤70%
Dimension 225(W)×143(H)×278(D) mm 225(W)×143(H)×278(D) mm
Weight ≈ 8.0kg ≈ 8.0kg

Note* Specifications are liable to change. For the full list of Specifications, please see the products datasheet located under the ‘Documentation’ tab.
