TekBox TBST86/49/45/1 (Without AC Filter) Small EMI Shield Tent

£1227.00 (£1472.4 inc VAT)

FREE UK delivery: on all orders above £100+vat

Availability: Stock models delivered next working day (UK only) for orders placed before 15:00 (Mon - Fri)

Only 2 left in stock!

SKU: TBST86-49-45-1 Category:

Description

The Tekbox TBST range of shielded tents is designed to suppress interference from ambient noise when carrying out EMC pre-compliance measurements. With the size of 86cm x 49cm x 45cm, it can accommodate any Tekbox pre-compliance test equipment such as LISN’s or TEM-Cells.
The shielded tent is composed of two layers of conductive fabrics. It is supported by rigid aluminium profiles.

The filter panel at the side provides:

  • 2 x 240V/10A DC filters
  • 4 x coaxial feed through adapters with screw caps
  • 1 x BNC-Female feed through connector

The access opening is sealed with conductive Velcro tape.

Specifications:

  • Outer Dimensions: 86cm x 49cm x 45cm
  • Opening Dimensions: 40cm x 22cm
  • Frame: 20mm x 20mm Extruded aluminium profiles
  • Shielding: 2 Layers of conductive fabrics
  • Seal: Conductive Velcro tape
  • Suspension: Velcro Stripes
  • Weight: 10.8kg

NOTE: The TBST86/49/45/1 does NOT come with an AC Filter or IEC Socket.
If you require the tent to have these features please see the TBST86/49/45/2.
